Detect Five Kinds of Radiation Multi Purpose Radioactive Survey Meter
FJ-1015 multi-function radiation patrol instrument can detect five kinds of radiation, such as alpha, beta, X, gamma and neutron. It can measure environmental radiation level and surface contamination. It can also select carbon fiber extension rod and ultra-large dose radiation probe. It is the best choice for rapid response and nuclear emergency.
Hardware configuration
1.Imported Saint-Gobain Cake Detector
2.High Strength ABS Shell
3.Large-screen LCD
4.4G Large Capacity SD Card (Storing 100,000 Groups of Data)
5.Patented High Voltage Circuit Module
6.Patented Energy-saving Circuit Module
7.485 Fast Interpolation Interface
8.Connect Spring Data Line with Expanded Probe
9.USB interface
10.On-line USB Data Line with PC
11.Data Analysis CD-ROM for PC
12.5# Battery 2 Section
Typical configuration technical parameters:
| Main Detector (1015 Detector) | Saint-Gobain Cake GM Detector |
| Detector area | 15.69cm 2 |
| Dose rate range | 1nSv/h~100mSv/h |
| Measurement range of counting rate | 0-106 CPS |
Cumulative dose range: 0-999999mSv
Sensitivity: 3500 CPM/mR/h (for Cs-137)
Alpha-ray energy range: 2.6 MeV and above
Beta-ray energy range: 100 keV and above
X and gamma energy ranges: 10 keV~3 MeV
Data storage space: 4G
Shell Material: Yellow ABS
Power-on working hours: > 72 hours
Relative basic error: +10%
Display units: mu Sv/h, mSv/h, mR/h, mu Gy/h, mGy/h, cps, cpm, mSv
Threshold Setting: Regular 3-fold Continuous Adjustment from Background
Alarm items: over-threshold alarm, detector fault alarm, low-power alarm, over-range alarm
Alarm mode: Acousto-optic alarm and vibration alarm can be combined arbitrarily
Self-protection: Over-threshold Self-protection
Display: color display screen, all data display on the same screen, with backlight function
Expansibility: With external fast plug, the probe can be expanded quickly.
Emergency: Start up for 1 second without preheating; alarm within 5 seconds of exceeding threshold
Packaging Protection Level: IP65
Temperature range: - 20 ~60 ~
Humidity range: <98% (40 C)
Weight: about 340g
